CF10

Point Source

Available early 2024
Weight
28.2 lbs / 12.8 kg
Size (HxWxD)
11.47 in. x 16.50 in. x 9.66 in.
291.4 mm x 419.1 mm x 245.2 mm
Directivity
100° H x 60° V Rotatable (Standard)
(Optional)
Max spl
136 dB SPL @ 1 M
Bandwidth
62 Hz–18 kHz (+/-3 dB) / 50 Hz–19 kHz (-10 dB)
available for
Rental
Purchase
Rental & Purchase

Product Description

The CF10 represents the epitome of the Cohesion line of fill products. With a maximum SPL of 136 dB and an extended frequency response down to 50 Hz, the CF10 delivers performance typically found in a 12” enclosure in a significantly more compact form factor.

Its innovative design boasts a rotatable horn, built-in monitor angle, and a convenient pole cup, which offers nearly limitless placement options for multiple applications. Use the available yoke mount to place the CF10 nearly anywhere your production or installation requires. The CF10 pairs well with CO Series arrays for full sound and coverage, or it may be used on its own.

The CF10 is built with premium weather-resistant components to ensure reliability in harsh environmental conditions. Cohesion products are designed and assembled in the USA.

Product Features

  • Two-Way (Single Amplifier Channel Passive)
  • Frequency Response (+/- 3 dB): 62 Hz–18 kHz
  • Frequency Response (-10 dB): 50 Hz–19 kHz
  • Max. Output: 136 dB SPL @ 1 M
  • Drivers: LF: (1) 10 in. (254.0 mm) Cone Driver / HF: (1) 3 in. (76.2 mm) Voice Coil Compression Driver
  • Nominal Impedance: 8 Ohms
  • Directivity: Standard: 100° H x 60° V Rotatable
  • Input Connection: (2) NL4 connectors, (1) 4-pin terminal block
There are no accessories available for this product right now. For updates or inquiries, don’t hesitate to contact us.

Rigging

#
18496
CF10 Vertical Mounting Bracket

#
18495
CF10 Horizontal Mounting Bracket

Transportation

There are currently no accessories available.

Covers

There are currently no accessories available.
