CF28

Point Source

Available early 2024
Weight
46 lbs / 20.9 kg
Size (HxWxD)
9.75 in. x 23.83 in. x 13.75 in.
247.7 mm x 605.2 mm x 349.3 mm
Directivity
120° H x 50° V Rotatable (Standard)
(Optional)
Max spl
142 dB SPL @ 1 M
Bandwidth
52 Hz - 19kHz (+/-3 dB) / 46 Hz - 20 kHz (-10 dB)
available for
Rental
Purchase
Rental & Purchase

Product Description

The CF28 is a powerful performer within the Cohesion series of fill products. It is both useful on its own or as a low-profile solution to seamlessly integrate with larger systems.

Its robust yet compact design offers flexibility in placement options, ensuring optimal performance when on stage, filling in gaps, or virtually any other application. With the available yoke mount accessory, the CF28 provides even more flexibility and can also be pole mounted. The CF28 pairs well with CO Series arrays for full sound and coverage, or it may be used on its own.

The CF28 is built with premium weather-resistant components to ensure reliability in harsh environmental conditions. Cohesion products are designed and assembled in the USA.

Product Features

  • Three-Way (Single Amplifier Channel Passive)
  • Frequency Response (+/- 3 dB): 52 Hz - 19 kHz
  • Frequency Response (-10 dB): 46 Hz - 20 kHz
  • Max. Output: 142 dB SPL @ 1 M
  • Drivers: LF: (2) 8 in. (203 mm) Cone Drivers / MF: (1) 3 in. (76 mm) voice coil Compression Driver / HF: (1) 2 in. (51 mm) Voice Coil Compression Driver
  • Nominal Impedance: 8 Ohms
  • Directivity: Standard: 120° H x 50° V Rotatable
  • Input Connection: (2) NL4 connectors, (1) 4-pin terminal block
There are no accessories available for this product right now. For updates or inquiries, don’t hesitate to contact us.

Rigging

#
18492
CF28 Horizontal Mounting Bracket

Transportation

There are currently no accessories available.

Covers

There are currently no accessories available.
